Description
Features
- Capped Low-Profile Turrets
- 30mm Mono-tube chassis
- Wide Angle
- Illumination
- 11 layer Fully Multi-Coated lenses
- High torque zoom ring
- Fast focus eyebell
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Objective Lens
56mm
Reticle
L4A Dot (2 MOA)
Illumination
5 Levels (Red & Green)
Illumination Control
Stepped Rheostat
Parallax
Fixed
Magnification
3 – 12x
Optical System
System H2
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
43.8 – 11.4ft @100yds
14.6 – 3.8m @100m
Field of View (°)
8.4 – 2.2
Eye Relief
3.5in
90mm
PX/Focus
100yds
91m
Exit Pupil
0.74 – 0.19″
18.7 – 4.7mm
Click Value
1⁄ 4MOA
Elevation Turret Clicks (max)
100 MOA
Windage Turret Clicks (max)
100 MOA
Ocular Type
Fast Focus
Power Selector
Knurled Posi-Grip
Lens Coating
Fully Multi-Coated – 11 Layers
Length
13.4in
341mm
Weight
23.6oz
669g
Turret Type (Elevation)
Capped. Low-Profile. Resettable
Turret Type (Windage)
Capped. Low-Profile. Resettable
