Description
Objective Lens
32mm
Reticle
AMX IR
Illumination
6 Levels (Red)
Illumination Control
Stepped Rheostat with Off Positions In-between
Parallax
Side Focus
Magnification
3 – 12x
Optical System
System H2
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
63.8 – 18.2ft @100yds
21.3 – 6.1m @100m
Field of View (°)
12.1 – 3.5
Eye Relief
1.2in
30mm
PX/Focus
8yds – ∞
7m – ∞
Exit Pupil
0.42 – 0.11″
10.7 – 2.7mm
Click Value
1⁄ 10MRAD
Elevation Turret Clicks (max)
75 MRAD
Windage Turret Clicks (max)
75 MRAD
Ocular Type
Locking Fast Focus
Power Selector
Knurled Posi-Grip
Lens Coating
Fully Multi-Coated – 16 Layers
Length
10.5in
266mm
Weight
20.2oz
572g
Turret Type (Elevation)
Target. Capped. Resettable
Turret Type (Windage)
Target. Capped. Resettable
