Description
Features
- Exposed Locking Turrets
- 30mm Mono-tube chassis
- Wide Angle
- Side Focus
- Illumination
- 11 layer Fully Multi-Coated lenses
- High torque zoom ring
- Fast focus eyebell
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Objective Lens
50mm
Reticle
Rimfire .22 LR HV (16x)
Illumination
5 Levels (Red & Green)
Illumination Control
Stepped Rheostat
Parallax
Side Focus
Magnification
4 – 16x
Optical System
System H2
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
28.8 – 7.8ft @100yds
9.6 – 2.6m @100m
Field of View (°)
5.5 – 1.5
Eye Relief
3.5in
90mm
PX/Focus (Error free from)
10yds – ∞
9m – ∞
Exit Pupil
0.49 – 0.12″
12.5 – 3.1mm
Click Value
1⁄ 4MOA
Elevation Turret Clicks (max)
96 MOA
Windage Turret Clicks (max)
96 MOA
Ocular Type
Fast Focus
Power Selector
Knurled Posi-Grip
Lens Coating
Fully Multi-Coated – 11 Layers
Length
13.7in
347mm
Weight
26.1oz
740g
Turret Type (Elevation)
Exposed. Locking. Resettable
Turret Type (Windage)
Exposed. Locking. Resettable
