Description
Features
- Patented Exposed Zero Lock ‘n’ Stop elevation turret
- 30mm Mono-tube chassis
- Side Focus
- Illumination
- Wide Angle FOV
- High volume eyebox
- 100mm eye relief
- Multi-LED high intensity reticle
- High grade, low dispersion Crown glass
- 21 layer Fully Multi-Coated lenses
- Zoom magnification throw lever (removable)
- Fast focus eyebell with lock ring
- Supplied with Professional metal flip-up covers.
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Objective Lens
56mm
Reticle
LR Dot (16x)
Illumination
6 Levels (Red)
Illumination Control
Stepped Rheostat with Off Positions In-between
Parallax
Side Focus
Magnification
5 – 30x
Optical System
System H7
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
22.5 – 3.6ft @100yds
7.5 – 1.2m @100m
Field of View (°)
4.3 – 0.7
Eye Relief
4in
102mm
PX/Focus
15yds – ∞
14m – ∞
Exit Pupil
0.44 – 0.07″
11.2 – 1.9mm
Click Value
1⁄ 4MOA
Elevation Turret Clicks (max)
60 MOA
Windage Turret Clicks (max)
60 MOA
Ocular Type
Locking Fast Focus
Power Selector
Knurled Posi-Grip with Removable Zoom Lever
Lens Coating
Fully Multi-Coated – 21 Layers
Length
15.8in
401mm
Weight
25.5oz
724g
Turret Type (Elevation)
Zero Lock ‘n’ Stop. Exposed. Locking. Resettable
Turret Type (Windage)
Exposed. Locking. Resettable
