Description
Features
- Patented Exposed Zero Lock ‘n’ Stop elevation turret
- 30mm Mono-tube chassis
- Side Focus
- Illumination
- Wide Angle FOV
- High volume eyebox
- 100mm eye relief
- Multi-LED high intensity reticle
- High grade, low dispersion Crown glass
- 21 layer Fully Multi-Coated lenses
- Zoom magnification throw lever (removable)
- Fast focus eyebell with lock ring
- Supplied with Professional metal flip-up covers.
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Objective Lens
50mm
Reticle
LR Dot (16x)
Illumination
6 Levels (Red)
Illumination Control
Stepped Rheostat with Off Positions In-between
Parallax
Side Focus
Magnification
4 – 24x
Optical System
System H7
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
28.2 – 4.8ft @100yds
9.4 – 1.6m @100m
Field of View (°)
5.4 – 0.9
Eye Relief
4in
102mm
PX/Focus
15yds – ∞
14m – ∞
Exit Pupil
0.49 – 0.08″
12.5 – 2.1mm
Click Value
1⁄ 4MOA
Elevation Turret Clicks (max)
75 MOA
Windage Turret Clicks (max)
75 MOA
Ocular Type
Locking Fast Focus
Power Selector
Knurled Posi-Grip with Removable Zoom Lever
Lens Coating
Fully Multi-Coated – 21 Layers
Length
14.5in
369mm
Weight
23.4oz
662g
Turret Type (Elevation)
Zero Lock ‘n’ Stop. Exposed. Locking. Resettable
Turret Type (Windage)
Exposed. Locking. Resettable
