Description
Features
- Capped Low-Profile Turrets
- 30mm Mono-tube chassis
- Illumination
- Wide Angle FOV
- High volume eyebox
- 100mm eye relief
- Multi-LED high intensity reticle
- High grade, low dispersion Crown glass
- 21 layer Fully Multi-Coated lenses
- Zoom magnification throw lever (removable)
- Fast focus eyebell with lock ring
- Supplied with Professional metal flip-up covers.
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Objective Lens
24mm
Reticle
L4A Dot (2 MOA)
Illumination
6 Levels (Red)
Illumination Control
Stepped Rheostat with Off Positions In-between
Parallax
Fixed
Magnification
1 – 6x
Optical System
System H7
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
112.8 – 18.9ft @100yds
37.6 – 6.3m @100m
Field of View (°)
21.3 – 3.6
Eye Relief
4in
102mm
PX/Focus
100yds
91m
Exit Pupil
0.94 – 0.16″
24 – 4mm
Click Value
1⁄ 2MOA
Elevation Turret Clicks (max)
140 MOA
Windage Turret Clicks (max)
140 MOA
Ocular Type
Locking Fast Focus
Power Selector
Knurled Posi-Grip with Removable Zoom Lever
Lens Coating
Fully Multi-Coated – 21 Layers
Length
11.1in
283mm
Weight
17.5oz
495g
Turret Type (Elevation)
Capped. Low-Profile. Resettable
Turret Type (Windage)
Capped. Low-Profile. Resettable
