Description
Features
- Patented Exposed Zero Lock ‘n’ Stop elevation turret
- 30mm Mono-tube chassis
- Fibre Optic Illumination
- Wide Angle FOV
- High volume eyebox
- 100mm eye relief
- High grade, low dispersion Crown glass
- 21 layer Fully Multi-Coated lenses
- Zoom magnification throw lever (removable)
- Fast focus eyebell with lock ring
- Supplied with Professional metal flip-up covers.
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Objective Lens
24mm
Reticle
MOA FD (10x)
Illumination
11 Levels (Red)
Illumination Control
Stepped Rheostat with Off Positions In-between
Parallax
Fixed
Magnification
1 – 10x
Optical System
System H7
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
116.3 – 11.6ft @100yds
38.8 – 3.9m @100m
Field of View (°)
21.9 – 2.2
Eye Relief
4in
102mm
PX/Focus
100yds
91m
Exit Pupil
0.94 – 0.09″
24 – 2.4mm
Click Value
1⁄ 4MOA
Elevation Turret Clicks (max)
135 MOA
Windage Turret Clicks (max)
135 MOA
Ocular Type
Locking Fast Focus
Power Selector
Knurled Posi-Grip with Removable Zoom Lever
Lens Coating
Fully Multi-Coated – 21 Layers
Length
11.1in
283mm
Weight
19oz
540g
Turret Type (Elevation)
Zero Lock ‘n’ Stop. Exposed. Locking. Resettable
Turret Type (Windage)
Exposed. Locking. Resettable
