Description
Objective Lens
44mm
Reticle
AMX IR
Illumination
6 Levels (Red)
Illumination Control
Stepped Rheostat with Off Positions In-between
Parallax
Side Focus
Magnification
4 – 16x
Optical System
System H2
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
32.8 – 8.2ft @100yds
10.9 – 2.7m @100m
Field of View (°)
6.3 – 1.6
Eye Relief
3in
76mm
PX/Focus (Error free from)
10yds – ∞
9m – ∞
Exit Pupil
0.43 – 0.11″
11 – 2.8mm
Click Value
1⁄ 10MRAD
Elevation Turret Clicks (max)
20 MRAD
Windage Turret Clicks (max)
20 MRAD
Ocular Type
Fast Focus
Power Selector
Knurled Posi-Grip
Lens Coating
Fully Multi-Coated – 16 Layers
Length
11.7in
296mm
Weight
21.9oz
621g
Turret Type (Elevation)
Target. Capped. Resettable
Turret Type (Windage)
Target. Capped. Resettable
