Description
Features
- 18 Layer Fully Multi-Coated Lenses
- Capped, Low-Profile, Resettable Turrets
- High Torque Rubber Zoom Ring with Removable Throw Lever
- High Grade, Low Dispersion Crown Glass
- Red Digital Fibre Optic Illumination x11 levels
- Push-Button Illumination with Auto-Standby and Motion Activation
- Fast Focus Eyebell – 102mm Eye Relief
- 30mm Mono-tube Chassis
Objective Lens
50mm
Reticle
LR2 FD (12x)
Illumination
11 Levels (Red)
Illumination Control
Digital Push-Button
Parallax
Fixed
Magnification
2 – 12x
Optical System
System H5
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
58.2 – 9.7ft @100yds
19.4 – 3.2m @100m
Field of View (°)
11.1 – 1.9
Eye Relief
4in
102mm
PX/Focus
100yds
91m
Exit Pupil
0.98 – 0.17″
25 – 4.2mm
Click Value
1⁄ 4MOA
Elevation Turret Clicks (max)
140 MOA
Windage Turret Clicks (max)
140 MOA
Ocular Type
Fast Focus
Power Selector
Rubber Coated Posi-Grip with Removable Zoom Lever
Lens Coating
Fully Multi-Coated – 18 Layers
Length
13.1in
334mm
Weight
21.5oz
610g
Turret Type (Elevation)
Capped. Low-Profile. Resettable
Turret Type (Windage)
Capped. Low-Profile. Resettable
