Description
Main Specifications
-
Sensor: 17 µm, 384 × 288
-
Objective Lens: F30/1.2
-
Magnification: 2 – 8× (4× zoom)
-
FOV (HxV), degrees: 13.3 × 10
-
FOV (HxV), m @ 100 m: 23.3 × 17.5
-
Detection Range: 1050 m
Sensor
-
Type: Uncooled
-
Resolution, pixels: 384 × 288
-
Pixel Pitch, µm: 17
-
Sensor NETD, mK: < 25
-
System NETD, mK: < 20
-
Frame Rate, Hz: 50
Optics
-
Objective Lens: F30/1.2
-
Magnification: 2 – 8× (4× zoom)
-
FOV (HxV), degrees: 13.3 × 10
-
FOV (HxV), m @ 100 m: 23.3 × 17.5
-
Eye Relief, mm: 14
Display
-
Type: AMOLED HD
-
Resolution, pixels: 640 × 400
Range Performance
-
Detection Range, m: 1050
Video Recorder
-
Video / Photo Resolution, pixels: 528 × 400
-
Video / Photo Format: .mp4 / .jpg
-
Built-in Memory, GB: 16
Wi-Fi
-
Wireless Protocol: Wi-Fi
-
Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
-
Frequency, GHz: 2.4 / 5
Environmental Characteristics
-
Degree of Protection: IPX7 (waterproof)
-
IP Code Standard: IEC 60529
-
Operating Temperature Range, °C: -25 to +40
Connections & Compatibility
-
Mount Type: 1/4″
-
Compatible Mounts: Tripods
-
Supported Application: Stream Vision 2
Power Supply
-
Output Voltage, V: 3.0 – 4.2
-
Battery Type: APS 3 Li-ion Battery Pack
-
Capacity, mAh: 3200
-
Operating Time, h: 7.5 (at 22 °C)
-
External Power Supply, V: 5 (USB Type-C)
Weight & Size
-
Body Material: Magnesium alloy
-
Dimensions, mm: 144 × 41 × 69
-
Weight, kg: 0.25 (without battery)
Product Info
-
SKU: 77506
