Description
Main Specifications
Sensor: 12 µm, 640×480
Objective Lens: F30/1.2
Magnification: 2 – 16× (x8 zoom)
FOV (HxV), degrees: 14.6 x 9.2
FOV (HxV), m @ 100m: 25.6 x 16.0
Detection Range: 1300 m
Sensor
Type: Uncooled
Resolution, pixels: 640×480
Pixel Pitch, µm: 12
Sensor NETD, mK: < 40
System NETD, mK: < 25
Frame Rate, Hz: 50
Optics
Objective Lens: F30/1.2
Magnification: 2 – 16× (x8 zoom)
FOV (HxV), degrees: 14.6 x 9.2
FOV (HxV), m @ 100m: 25.6 x 16.0
Eye Relief, mm: 14
Display
Type: AMOLED
Resolution, pixels: 640×400
Range Performance
Detection Range, m: 1300
Video Recorder
Video / Photo Resolution, pixels: 960×600
Video / Photo Format: .mp4 / .jpg
Built-in Memory, GB: 64
Wi-Fi
Wireless Protocol: Wi-Fi
Wireless Standard: IEEE 802.11 b/g/n/ac (WPA)
Frequency, GHz: 2.4 / 5
Environmental Characteristics
Degree of Protection: IPX7 (waterproof)
IP Code Standard: IEC 60529
Operating Temperature Range, °C: -20 to +40
Connections & Compatibility
Mount Type: 1/4″ socket
Compatible Mounts: Tripods
Supported Application: Stream Vision 2
Power Supply
Output Voltage, V: 3.0 – 4.2
Battery Type: Li-Ion Battery Pack APS 3
Capacity, mAh: 3200
Operating Time, h: 7 (at 22°C)
External Power Supply, V: 5 (USB Type C)
Weight & Size
Body Material: Magnesium alloy
Dimensions, mm: 144x41x69
Weight, kg: 0.25 (without battery)
Product Info
SKU: 77508
