Description
Features
- Resettable locking turrets with witness window
- 30mm Mono-tube chassis
- Side Focus
- Illumination
- Side wheel – index-matched (removable)
- Ultra-wide Angle 24° FOV
- High volume eyebox
- 100mm eye relief
- Multi-LED high intensity reticule
- High grade, low dispersion Crown glass
- 18 layer Fully Multi-Coated lenses
- Zoom magnification throw lever (removable)
- Fast focus eyeball with lock ring
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Objective Lens
50mm
Reticle
FFP Half Mil (16x)
Illumination
6 Levels (Red)
Illumination Control
Stepped Rheostat with Off Positions In-between
Parallax
Side Focus
Magnification
4 – 16x
Optical System
System H5
Focal Plane
FFP (First Focal Plane)
Scope Tube
30mm
Field of View
31.8 – 8.1ft @100yds
10.6 – 2.7m @100m
Field of View (°)
6.1 – 1.5
Eye Relief
4in
102mm
PX/Focus (Error free from)
10yds – ∞
9m – ∞
Exit Pupil
0.49 – 0.12″
12.5 – 3.1mm
Click Value
1⁄ 10MRAD
Elevation Turret Clicks (max)
26 MRAD
Windage Turret Clicks (max)
26 MRAD
Ocular Type
Locking Fast Focus
Power Selector
Knurled Posi-Grip with Removable Zoom Lever
Lens Coating
Fully Multi-Coated – 18 Layers
Length
13.3in
339mm
Weight
25.6oz
725g
Turret Type (Elevation)
Witness Window. Exposed. Locking. Resettable
Turret Type (Windage)
Witness Window. Exposed. Locking. Resettable
