Description
LCD Display
- Aim point with horizontal and vertical guides.
- Measuring units (M = meters, Y = yards)
- Distance readout
- Targeting modes
- Horizontal and angle readout
- Laser emission signal
- Low battery indicator
Objective Lens
42mm
Colour
Green
Magnification
10x
Optical System
System H7
Field of View (°)
6
Eye Relief
0.6in
16mm
Exit Pupil
0.17″
4.2mm
Lens Coating
Wide Band / Anti-reflection / Fully Multi-Coated Lenses
with Water Repellent Coating
with Water Repellent Coating
Field of View
315ft @1000yds
105m @1000m
Apparent Field of View (°)
60
Interpupillary Distance
2.2 – 3″
2.2 – 3mm
Close Focus
33ft
10.1m
Prism Type
Patented Prism System with Beam Split Coating
Eye Cups
Twist-Up (Replaceable)
Diopter Type
Left Eye
Tripod Mounting Thread
No
Modes
Standard // Horizontal Distance // Angle // Rain // Near // Hunt
Display
OLED
Range (yds)
11 – 2515
Range (m)
10 – 2300
Accuracy (yds)
±1
Accuracy (m)
±1
Angle Range
90º
Battery
3V CR2
Waterproof
IPX7
Width
4.5 – 5.4″
115 – 138mm
Height
7″
178mm
Weight
37oz
1048g
