Description
Features
- Capped Low-Profile Turrets
- 30mm Mono-tube chassis
- Illumination
- Ultra-wide Angle 24° FOV
- High volume eyebox
- 100mm eye relief
- Multi-LED high intensity reticle
- High grade, low dispersion Crown glass
- 18 layer Fully Multi-Coated lenses
- High torque rubber zoom ring
- Fast focus eyebell
Objective Lens
44mm
Reticle
L4A Dot (2 MOA)
Illumination
6 Levels (Red)
Illumination Control
Stepped Rheostat with Off Positions In-between
Parallax
Fixed
Magnification
1.5 – 6x
Optical System
System H5
Focal Plane
SFP (Second Focal Plane)
Scope Tube
30mm
Field of View
82.9 – 20.7ft @100yds
27.6 – 6.9m @100m
Field of View (°)
15.7 – 4
Eye Relief
4in
102mm
PX/Focus
100yds
91m
Exit Pupil
1.15 – 0.29″
29.3 – 7.3mm
Click Value
1⁄ 4MOA
Elevation Turret Clicks (max)
180 MOA
Windage Turret Clicks (max)
180 MOA
Ocular Type
Fast Focus
Power Selector
Rubber Coated Posi-Grip
Lens Coating
Fully Multi-Coated – 18 Layers
Length
13.2in
336mm
Weight
20.1oz
569g
Turret Type (Elevation)
Capped. Low-Profile. Resettable
Turret Type (Windage)
Capped. Low-Profile. Resettable
